Aruba Instant On AP17 (RW) Access Point (R2X11A)
Aruba Instant On AP17 (RW) Access Point (R2X11A) - Image 2
Aruba Instant On AP17 (RW) Access Point (R2X11A) - Image 3
Aruba Instant On AP17 (RW) Access Point (R2X11A) - Image 4
Aruba Instant On AP17 (RW) Access Point (R2X11A) - Image 5

Aruba Instant On AP17 (RW) Access Point (R2X11A)

800.00 ر.س 720.00 ر.س

Outdoor Access Point with dual-band Wi-Fi 5, 2×2:2 MU-MIMO, Smart Mesh, 1x RJ-45 10/100/1000 PoE port, IP55-rated rugged enclosure, and mobile app cloud management for secure, scalable outdoor networking.

Categories: , Tags: ,

Description



Aruba Instant On AP17 (R2X11A) | Outdoor Dual-Band Wi-Fi 5 Access Point with Smart Mesh & PoE

Engineered for businesses seeking high-performance outdoor Wi-Fi, the Aruba Instant On AP17 (R2X11A) delivers reliable, secure, and scalable connectivity. Designed to withstand harsh environments, it integrates cloud-based management, Smart Mesh networking, and enterprise-grade security—ideal for modern IT infrastructures across campuses, warehouses, and hospitality settings.

Features

High-Speed Outdoor Wireless Connectivity

Dual-radio 802.11ac Wave 2 (Wi-Fi 5) access point with:

  • Up to 867 Mbps on 5GHz
  • Up to 300 Mbps on 2.4GHz
  • 2×2:2 MU-MIMO support for seamless multi-user performance

Smart Mesh Technology

  • Enables wireless network expansion without extra cabling
  • Automatically optimizes performance and coverage across large areas

Simplified Cloud-Based Management

  • Easily managed via Aruba Instant On mobile app or cloud web portal
  • Quick setup with built-in DHCP/NAT and step-by-step guidance

Enterprise-Grade Security

  • Supports WPA2, WPA3, and Enhanced Open (OWE) protocols
  • Secure guest and employee traffic isolation
  • Built-in traffic shaping and per-user bandwidth limiting

Rugged Outdoor Design

  • IP55-rated enclosure built to perform in rain, snow, hail, and high heat
  • Operating temperature: -40°C to +50°C
  • MTBF: 300,000 hours for long-term reliability

Compact and Flexible Mounting

  • Includes wall mount bracket (supports wall or pole installation)
  • Optional mounting accessories available

Technical Specifications

Model: Aruba Instant On AP17 (R2X11A)
Wireless Standards:

  • Dual-band 802.11ac Wave 2 (Wi-Fi 5)
  • Bluetooth Low Energy (BLE)

Antennas:

  • Integrated omnidirectional antennas
  • 4.7 dBi @ 2.4GHz / 4.2 dBi @ 5GHz

Ports & Power:

  • 1x Gigabit Ethernet (RJ45) with PoE-in (802.3af)
  • Max Power Consumption: 13.5W
  • PoE injector sold separately

Dimensions:

  • 156 x 67 x 187 mm
    Weight:
  • 650g (1.43 lb)

Certifications:

  • Wi-Fi Alliance 802.11ac
  • WPA2, WPA3, OWE
  • UL2043, IEC 60950/62368 CB

Warranty:

  • 1-Year Limited Warranty
  • 24/7 Phone Support (first 90 days)
  • Ongoing Chat and Community Support

Ideal For

  • Outdoor enterprise environments, including campuses, hotels, warehouses, and retail
  • Small and medium businesses (SMBs) expanding their outdoor wireless coverage
  • IT managers seeking secure, easily managed cloud-based networking solutions
