JL683A

Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch (JL683A)

request to get the price

The Aruba Instant On 1930 switch series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The Aruba Instant On 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1G SFP slots on 8-port model and 1G/10G SFP+ slots on 24-/48G models for fiber connectivity.

Request
Categories: , Tags: ,

Description

Features

  • Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity.
  • Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility.
  • 1G/10G SFP+ ports on 24-and 48-port models for fiber connectivity.
  • Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
  • Option to manage your switches through local web GUI.
  • Limited Lifetime Warranty.

Specification

Differentiator Advanced, smart-managed, fixed-configuration Gigabit switches designed for small businesses. Easy-to-deploy, secure and affordable. The first switches with Instant On “anywhere, anytime” configuration and management. Using the Instant On mobile app or the cloud-based web portal, quickly setup, monitor and manage the 1930 switch. Can also choose to manage the device through the local web GUI. This model has 24 10/100/1000 RJ-45 and 4 SFP 1/10GbE ports. Provides 195 W Class 4 PoE power.

Power consumption 234.0 W maximum, 19.3 W idle

Input voltage 100 – 127 / 200 – 240 VAC

Ports 24 RJ-45 10/100/1000 ports, 4 SFP 1/10GbE ports

Switching capacity 128 Gbps

Throughput 95.23 Mpps, maximum

Memory and processor ARM Cortex-A9 @ 800 MHz
512 MB SDRAM, 256 MB flash
1.5 MB packet buffer

PoE capability 195 W Class 4

Management features Aruba Instant On Portal, Web browser, SNMP Manager

Warranty Limited Lifetime Warranty with 24×7 phone support for 90 days and chat support for the entire warranty duration

Weight 3.50 kg (7.71 lb)

Dimensions 4.39 x 44.25 x 26.47 cm (1.73 x 17.42 x 10.42 in)
